Neon Model and Sensor Specifications

Model Name	NEON-201B	NEON-202B	NEON-203B	NEON-204B	NEON-201A	NEON-202A
Image Sensor spec.	USB3	USB3	USB3	USB3	MIPI CSI	MIPI CSI
Resolution (HxV)	1280 x 960	1600 x 1200	1920 x 1080	2592 x 1944	1920 x 1200	3840 x 2160
Resolution	1.2M	1.9M	2M	5M	2M	8M
Frame Rate (fps)	54	60	30	14	60	30
Color/Mono	Color	Color	Color	Color	Color	Color
Shutter	Global	Global	Rolling	Rolling	Global	Rolling
Sensor Size	¹⁄₃”	1/(1.8”)	1/(3.7”)	1/(2.5”)	1/(2.6”)	1/(1.8”)
Pixel Size (µm)	3.75 x 3.75	4.5 x 4.5	2.2 x 2.2	2.2 x 2.2	3 x 3	2.0 x 2.0
Sensor Vendor	ON Semiconductor	e2v	ON Semiconductor	ON Semiconductor	ON Semiconductor	SONY
Sensor Model	AR0134	EV76C570	MT9P031	MT9P031	AR0234	IMX334
Image sensor SDK	Basler pylon	Basler pylon	Basler pylon	Basler pylon	V4L2 & Gstreamer	V4L2 & Gstreamer

Please select the Model Name:

Please select the Lens:

Please enter WD (mm):

VFOV (mm):

HFOV (mm):

HFOV(mm/pixel):

VFOV(mm/pixel):

Image(H):

Image(V):

H_Angle:

V_Angle:

Pixel Size (µm):
